New version Face Recognition Body Temperature Measurement System Scanner Access Control For Entrance and Exit

  • 1 - 49 Pieces
  • 50 - 99 Pieces
  • >=100 Pieces
Face recognition (Face) Card CODE Face
wifi TCP Ip SDK
Customized support:
Online technical support Customized logo OEM, ODM
Face recognition (Face) , wifi , Online technical support
$1.00 /Piece | 1 Piece (Min. Order) | Buy Samples
Support Sea freight · Land freight
Lead Time:
Quantity(Pieces) 1 - 20 >20
Est. Time(days) 15 Negotiable
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 300 Pieces)


Graphic customization (Min. Order: 500 Pieces) Less
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Model Number:
1 Year
1280 X 720
ce, FCC, RoHS
Special Features:
Motion Detection, Temperature Measurement, People Counting, Built-in Siren, Two-way Audio, Thermal image, One-way Audio, Night vision (IR), Alarm I/O, NIGHT VISION
Data Storage Options:
Cloud, Memory Card
Indoor, Outdoor
Product Name:
Face Recognition attendance Access Controller with ai face temperature
8 inches
Detect distance::
Live detection::
Mask detection::
OSD language:
Multi language supported
Measurement Mode::
Thermographic temperature measurement
Overall Size:
Length 284 * width 140 * height 29mm
High-performance 32-bit 4-core ARM chip
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
color gift box, carton
shenzhen, guangzhou, hongkong, shanghai
Lead Time :
Quantity(Pieces) 1 - 20 >20
Est. Time(days) 15 To be negotiated
Product Description

 Temperature Measuring access control Fac Recognition time attendance Access Controller with ai face temperature

Model: JTA-TK-8




Technical Specifications

Hardware & Technical Specifications

System CPU RK3288, Quad Core,Cortex A17,1.8G
RAM & ROM 2GB + 8Gb
Operating System Android 7.1
Screen LCD display 8inch LCD
Resolution / Contrast 800*1280  / 800:1
Brightness 250 cd/m2
Touch Screen Non-touch(Touch optional)
screen ratio 16:9
Network WiFi 802.11b/g/n
Ethernet 100M/1000M RJ45 Port
Bluetooth Bluetooth 4.0
Camera Resolution 2 million pixels
Type Binocular wide dynamic camera
aperture F2.4
Focusing distance 50-150cm
White balance Auto
flash NIR: 850nm infrared LED light
Interface USB Hostx USB Host 2.0    *1
Wired network interface Ethernet interface
Serial interface 1 RS232 serial port
Relay output 1 door open signal output
Wiegand  Interface Wiegand 26/34 , one in & one out
Upgrade button Support Uboot Update button
Power jack DC input
Function Face Capacity Max 20k

1: N face recognition


1: 1 face comparison


Recognition distance configuration


Device upgrade remotely


UI interface configuration

Device interface Interfaces include device management, personnel / photo management, record query, etc.
Deployment method Support public cloud deployment, privatization deployment, LAN use, stand-alone use

Mask recognition

Stranger detection

Infrared thermal imaging module Human body temperature detection support
Temperature detection distance 1m(The best distance is 0.5 meters)
Temperature measurement accuracy ≤ ±0.3℃
Temperature measurement range 10℃~42℃
Visitor's body temperature is normally released directly support
Body temperature over temperature alarm Support (temperature alarm value can be set)
Media player Video format H.264,VP8,RV,WMV,AVS,H.263,MPEG4,etc
audio format MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP
Image Format JPG,BMP,PNG,etc. Support rotation / slide show / Picture zoom function
Others Speaker 1.5W/4R



Card reader

OSD language Multi language supported.
Operating temperature 0--40degree
General parameters power supply DC12V 3A
Operating temperature 0℃~40℃
Storage temperature -20℃~60℃
Installation method wall mount / floor stand (optional)
Power consumption 13.5W(Max)



Packaging & Shipping


 Optional Packing
1. Standard exported carton with foam inside
2. Outside Wooden case


Shenzhen / Guangzhou / Hong Kong / Shanghai

Lead Time:

          3-28 days after payments received.




Accepted Delivery Terms


FOB, CFR, CIF, EXW, DDP, DDU, Express Delivery

Accepted Payment Currency


Accepted Payment Type

T/T, L/C, D/P D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow

Company Information

About Snappy:

Snappy is the one-stop supplier of queue management system, digital signage & feedback management system
Snappy headquartered in Amsterdam - The Netherlands, which is famous for its innovative hi-tech industry. We have a manufacturing unit at Shenzhen - China, and have the financial management division at Dubai - UAE, and have the software development, support, marketing & call center at Thanjavur - India .
Our Services


1. Customized packing and customer’s logo are accepted.

2. Sample order is welcomed.

3. Provide various transport ways for by sea,by air or by freight company DHL,UPS,Fedex.

4. Factory Directly sale all over the world.

5. Follow the status of delivery time by time until the goods arrival.

6. Warrancy policy:12 month since shipment.



1. Do you support OEM service ?

   Yes , we support OEM service .


2. What's your best price?
Our products have a quite wide price ranges for different size and different system. Please contact us freely, we will be happy to give you a quotation upon receipt of your detailed requirements.


3.When and How can I get the price?

 We usually quote within 24hours after we get your inquiry.Please feel free to contact us on trademanager If you are very urgent to get the price.Please call us or contact us in your email so that we will regard your inquiry priority.


4.What’s your payment method ?

Various payment methods are available, Alibaba Trade Assurance,Western Union and T/T.

100% payment for little value bill; 30% deposit and 70% before shipping for big value bill.


5.What's the lead time?



6. Could you deliver the goods to our country ?

      Yes , Please see the picture as below .
